8" 300W RMS 4-Ohm 2" DVC Shallow Subwoofer DD Audio Slim Line Series SL608-D4

8" 300W RMS 4-Ohm 2" DVC Shallow Subwoofer DD Audio Slim Line Series SL608-D4

• Powerful Performance: Delivers a robust 300W RMS and can handle peak power with ease, providing deep and impactful bass in a compact design.
• Shallow Design: The slim profile of the SL608-D4 is perfect for installations where space is limited, allowing for flexible placement options without sacrificing sound quality.
• Dual Voice Coil Configuration: The 2" dual voice coil design offers enhanced wiring flexibility and optimal impedance matching for improved performance and sound clarity.
• High-Quality Construction: Built with premium materials, including a durable cone and high-strength surround, ensuring longevity and consistent performance even under demanding conditions.
• Versatile Installation: Ideal for both sealed and ported enclosures, making it a versatile choice for custom audio setups in various vehicle types.

8" 300W RMS 4-Ohm 2" DVC Shallow Subwoofer DD Audio Slim Line Series SL608-D4

This listing includes:

• (1) 8 Inch 600 Watt Hi-Def Tuned Shallow Subwoofer

Description:

Unleash powerful bass in a compact form with the DD Audio Slim Line Series SL608-D4. This 8" shallow subwoofer is engineered to deliver deep, impactful sound while fitting into tight spaces. Despite its slim profile, it packs a punch with 300W RMS, ensuring your music hits hard and clear. The dual 2" voice coils provide flexible wiring options and optimize impedance matching for superior audio performance. Crafted with high-quality materials, the SL608-D4 is designed to withstand rigorous use and maintain peak performance. Perfect for both sealed and ported enclosures, this subwoofer offers versatile installation possibilities, making it an excellent choice for enhancing your audio system without compromising on space.

Features:

• Shallow Mounting Depths
• 2" high temperature voice coil
• 72oz magnet, back plate coil gap venting
• EROM surround

Specifications:

• Speaker Size (In): 8
• Watts RMS: 100 - 300
• Watts Peak: 600
• Impedance: D4
• VCD (In): 2
• Piston Diameter (In): 6.5
• Fs (Hz): 34
• Qms: 5.139
• Qes: 0.432
• Qts: 0.398
• Vas (Liters): 13.106
• dBSPL: 84
• Xmech (MM): 38
• Xmax (MM): 12

Measurements:

• Frame OD (In): 8.31
• Frame OD (MM): 211.074
• Frame OD w/Gasket (In): 8.5
• Frame OD w/Gasket (MM): 215.9
• Mounting Diameter (In): 7.37
• Mounting Diameter (MM): 187.198
• Mounting Depth (In): 3.5
• Mounting Depth (MM): 88.9
• Motor Diameter (In): 5.276
• Motor Diameter (MM): 134.0104
• Motor Depth (In): 1
• Motor Depth (MM): 25.4
• Magnet Weight (Oz): 50
• Magnet Weight (Gm): 1417.48

Enclosure Suggestions:

• Woofer Displacement (CuFt): 0.04
• Woofer Displacement (Liters): 1.133
• Sealed Enclosure (CuFt): 0.30 - 0.70
• Sealed Enclosure (Liters): 8.495 - 19.822
• Ported Enclosure (CuFt): 0.4 - 1.0
• Ported Enclosure (Liters): 11.327 - 28.317
• Item Weight (Lbs): 9.42
