Rockford Fosgate
Rockford fosgate Power 400 Watt Class-ad 4-Channel Element Ready™ Amplifier
$629.99
In Stock
Pre-Order
Sold out
Couldn't load pickup availability
100% ORIGINAL AND QUALITY
24 MONTHS GUARANTEE
- Description
- Shipping and Refund
- Reviews
Rockford fosgate Power 400 Watt Class-ad 4-Channel Element Ready™ Amplifier
Product details
The TM400X4ad is a powerful and compact 400 Watt 4-channel amplifier. The amplifier features our proprietary high efficiency Class-ad topology for maximum power, sound quality and efficiency in full-range amplifier. It also integrates our patented Constant Power technology which results in up to 25% more output power. Top mounted controls feature our patented C.L.E.A.N. circuit to easily set your gains, integrated low-pass crossover, and our famous Punch EQ.
The amplifier also features high and low level inputs combined with our differential inputs to eliminate incoming noise. It can also provide a remote-out trigger when using high level inputs. Dual fan cooling, real time thermal monitoring and dual extruded heat sinks maintain heat dissipation even at high outputs keep the amp cool.
In addition to the conformal coated pc boards, the Element Ready™ design ads protection against water, dust and UV rays, making it great for multiple applications where it could be exposed to harsh outdoor environment.
FEATURES AT A GLANCE
- Rockford Fosgate proprietary Class AD technology
- C.L.E.A.N. input/output clip detection and indicator LEDs
- 8 AWG power/ground connector w/ upgraded RCA connectors
- Differential inputs with high level auto turn-on feature
- Remote-Out feature when using high level inputs
- 4/2 Ohm muti-impedance Constant Power
- Dual extruded heat sinks
- Top mounted controls
- Discrete surface mount technology
- Dual fan cooled
- Real time thermal sensing
- 4 Ohm bridged capable
- 2/4 channel input switch
- Marine grade two part epoxy coating on circuit boards
- 2-Year Warranty
Specifications
Cta-2006 Compliant
Number of Channels
4
Total Power
(Sum of Rated Power)
(Sum of Rated Power)
400 Watts
Rated Power
(RMS Continuous Power)
(RMS Continuous Power)
100 Watts x 4 @ 4-Ohm
100 Watts x 4 @ 2-Ohm
200 Watts x 2 @ 4-Ohm Bridged
100 Watts x 4 @ 2-Ohm
200 Watts x 2 @ 4-Ohm Bridged
Dynamic Power
(PVC/PowerCube®)
(PVC/PowerCube®)
128 Watts x 4 @ 4-Ohm
152 Watts x 4 @ 2-Ohm
290 Watts x 2 @ 4-Ohm Bridged
152 Watts x 4 @ 2-Ohm
290 Watts x 2 @ 4-Ohm Bridged
Bridgeable
Yes
Front Terminals: Left (+) Right (-)
Rear Terminals: Left (+) Right (-)
Front Terminals: Left (+) Right (-)
Rear Terminals: Left (+) Right (-)
Frequency Response
20Hz-20kHz +/-1dB
Input Sensitivity
150 mV to 12 V
Circuit Topology Class
Class AD
Efficiency (average)
>75%
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Front High/Low Level Input: 4-Pin harness
Rear High/Low Level Input: 4-Pin harness
Rear High/Low Level Input: 4-Pin harness
Signal Output
—
Tone Controls
Treble: 0 to +14 dB @ 12.5 kHz
Bass: 0 to +18 dB @ 45 Hz
Bass: 0 to +18 dB @ 45 Hz
Crossover Controls
High-Pass:
50Hz-250Hz @ 12dB/Octave Butterworth
Low-Pass:
50Hz-250Hz @ 12dB/Octave Butterworth
All-Pass: Yes
50Hz-250Hz @ 12dB/Octave Butterworth
Low-Pass:
50Hz-250Hz @ 12dB/Octave Butterworth
All-Pass: Yes
Remote Controls
—
Visual Indicators
Power: Blue LED
Protect: Red LED
Input Clip: Red LED3
Output Clip: Blue/Violet/Red LED1,2,3
LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Protect: Red LED
Input Clip: Red LED3
Output Clip: Blue/Violet/Red LED1,2,3
LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Power Wire Gauge
8 AWG
Power Input Connector
Speaker Wire Gauge
16 AWG
Speaker Output Connector
Front: 4-Pin Harness
Rear: 4-Pin Harness
Rear: 4-Pin Harness
Cooling
Dual Fan Cooled
Heatsink
Extruded Aluminum
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
(not included)
60 A
Average Current Draw (13.8V Music)
28 A
Max. Current Draw (13.8V Sinewave)
55 A
Suggested Alternator
75 A
Included In The Box
Dimensions (H x W x D)
1.6 x 4.3 x 8.3 (in.)
4.1 x 10.8 x 21.1 (cm)
4.1 x 10.8 x 21.1 (cm)
Shipping Weight
3.4 Lbs. (1.54 Kg.)
